- Installation Notes
1, the pneumatic valve must be cleaned, blown clean; such as impurities in the medium, in front of the valve pipeline should be installed filter valve.
2, before use, for the site installation of technical requirements for pneumatic valve specifications, parameters and accessories verification.
3, according to the pneumatic valve body arrow on the direction of installation (downstream installation) to connect the pneumatic valve interface with the pipeline, and ensure that the connection is well sealed.
4,When welding connection is required, avoid high temperature transmission to the packing etc. of the pneumatic valve.
5, before adding the valve, pay attention to the connection to ensure good sealing.
- Installation and installation of solenoid valves valve notes
1, must ensure that the fluid, gas source clean, in order to prevent clogging the solenoid valve or cylinder piston.
2, the solenoid valve coil is electrically charged, it is strictly prohibited to cover, in order to prevent overheating and burning.
3, the coil of the solenoid valve is charged, it is prohibited to remove to prevent electric shock.
4, solenoid valve coil, socket, solenoid tube and connecting parts, is strictly prohibited to hit the collision, in order to avoid damage.
5, the medium working pressure, working temperature, viscosity, shall not exceed the specified range.
6, the actual power supply voltage of the solenoid valve can not exceed the tolerance range.
7, the coil of the solenoid valve is charged with high heat during normal operation, do not touch.
8, the coil of the solenoid valve is charged, it is strictly prohibited to cover, in order to prevent overheating and burning.
- Maintenance methods
1, before disassembly, first of all, to be clear about the valve those high temperature, flammable and explosive or toxic, corrosive media, at the same time to drain the valve internal media pressure. Ensure equipment and personal safety.
2, disassembly steps:
A Remove the cylinder: remove the locking ring, lift up and remove the cylinder, you can see the piston, spring, position indicator, valve stem and other parts.
B Remove the valve body: use a wrench to rotate the root of the valve cover, that is, the valve body can be disassembled to see the valve body parts.
C Remove seals: after disassembling the valve body, you can see the seals at the end of the valve stem, unscrew the screws fixing the seals, you can remove the seals.
3,According to the fault analysis, the disassembled valve is processed accordingly. After processing, refer to the disassembly steps once installed.
4, the repaired valve, must do the pressure test and leakage test, there is no abnormality before installing and using again.
5, seals, locking rings, sealing rings and springs and other components must be installed in place, tighten the connection, the force should be uniform. Be careful not to touch the diaphragm and valve seat during disassembly and installation.
