Flanged Metal Seated Ball Valve

Flanged metal seat ball valve is a high-performance industrial valve with flange connection and metal seal structure, designed for high temperature and high pressure, strong corrosion and particle-containing media working conditions.

Advantages

Life expectancy extended by more than 3 times

Metal seal wear life far exceeds that of soft seal valves, reducing the frequency of downtime for replacement (e.g., coal chemical industry conditions);

Extremely low maintenance costs

Valve seats can be replaced online without disassembling the valve body ( Special modular design);

Zero loss of flow

Full bore design flow resistance coefficient ≤ 0.08, energy saving effect is remarkable;

High safety redundancy

Anti-static design (ball-stem-body conduction resistance <10Ω);

Valve cavity overpressure automatic relief (some models are equipped with pressure relief hole) Configuration of pressure relief hole).



Flanged Metal Seated Ball Valve



Features

Super pressure and temperature resistance

Maximum pressure resistance ≤420 bar (PN420), temperature range -196°C~550°C (LNG deep cooling to high temperature steam).

Zero Leakage Seal

The metal hard seal structure has a leakage rating of API 598 Class VI (leakage rate ≤ 10-⁶ mbar-L/s).

Resistant to scouring and abrasion

Hardened ball and seat can handle media containing ash and crystalline particles (e.g. coal chemical grey water, slurry).

Fire and explosion safety

All-metal construction is certified by API 607 for fire protection, and emergency shut-off is still possible after the soft seal melts.
