ss316 gate valve Description
316 stainless steel gate valve is a 316 stainless steel as the main material of the cut-off class valves, through the vertical movement of the gate to achieve the pipeline medium fully open or fully closed control, suitable for corrosive environments and high-pressure working conditions. Its core components include:
Valve body and gate: 316 stainless steel (containing 2-3% molybdenum elements, to enhance corrosion resistance), some models of the gate for the wedge-type or parallel double gate structure;
Sealing system: hard seal (metal-to-metal) or soft seal (metal + PTFE/rubber) design, adapted to different media characteristics;
Driving mode: manual, pneumatic or electric actuator, DN ≥ 300 recommended electric drive.
ss316 gate valve Specification
| Terms | Value range/specification |
|---|---|
| Nominal diameter | DN15~DN800(NPS 2~24) |
| Nominal pressure | PN1.6~20.0MPa(Class 150~2500) |
| Applicable temperature | -20℃~550℃(Soft seal materials limit low temperature range) |
| Applicable medium | Water, steam, acid/alkali solutions, fluids containing chloride ions, etc. |
|
item |
value |
|
Structure |
Gate |
|
Application |
General |
|
Place of Origin |
China |
|
Henan |
|
|
Power |
Manual |
|
Customized support |
OEM, ODM |
|
Port Size |
DN50-DN1000 |
|
Warranty |
1 year |
|
Temperature of Media |
Normal Temperature |
|
Brand Name |
GNEE |
|
Media |
Water |
|
Body material |
Stainless Steel304 316/Ductile Iron/Brass/Cast Steel |
|
Operation |
bevel gear,hand wheel |
|
Working medium |
Water, Waste Water, Air, Oil |
|
Seal Material |
Stainless Steel+STL;EPDM (120°C) /Viton(200°C)/PTFE(200°C) /NBR(90°C) |
|
Stem |
non-rising stem/rising stem |
|
Connection |
Flanged/Threaded Connection |
ss316 gate valve
Applications
Chemical industry: acid and alkali media transport pipelines, cut-off control of chloride-containing solutions;
Marine engineering: seawater desalination system, anti-corrosion isolation of ship pipelines;
Energy field: high-temperature steam pipeline, nuclear power plant cooling water system;
Food and medicine: aseptic fluid control with high hygiene requirements (surface polishing required)
