Irrigation check valve Description
Irrigation check valve is a one-way valve specially used in agricultural irrigation systems. It prevents water backflow through an automatic opening and closing mechanism to ensure safe and stable operation of irrigation equipment. Its core functions include:
Blocking backflow: The valve disc is quickly closed to prevent the water flow from impacting the pipeline and equipment in the opposite direction when the water pump stops;
Protecting the water pump: Avoiding the backflow of water from damaging the water pump impeller or drive motor, and extending the life of the equipment;
Maintaining system stability: Reduce the water hammer effect and avoid the failure of the irrigation system caused by pipeline pressure fluctuations.
Working principle
Forward flow: The water flow pressure pushes the valve disc (such as a rubber disc or a metal disc) to open, allowing the medium to pass normally;
Reverse flow: After the water pump stops, the valve disc automatically closes under gravity, spring force or backflow pressure to block the backflow of water.
Irrigation check valve specification
|
Product name |
irrigation system check valve |
|
Size |
3/4" 25mm --6"160mm; DN20--DN150 |
|
Connection |
Thread or Socket, slip connection |
|
Color of body |
Grey or White, or Customized color |
|
Certificate |
ISO, test report, Origin of Country, FORM A, FORM E.... |
|
Moq |
1 PCS |
|
Production capacity |
100000/month |
|
FOB price |
1.29--39.9 USD |
|
Port |
Tianjin, or China port |
|
Delivery date |
Within 2 weeks, up to the total quantity, maybe shorter |
|
Packing details |
1pcs 1 inner small box, outer strong cartons |
|
Payment Term |
TT / LC |
irrigation check valve
Advantages and solutions to industry pain points
| Advantages | Specific manifestations | Industry Problems Solved |
|---|---|---|
| Efficient sealing | Rubber/metal valve disc is suitable for different water qualities, and the blocking rate is ≥99%. | Preventing impurities from flowing back into the irrigation water and polluting the water source |
| Quick response | Valve disc closing time ≤ 0.5 seconds, reducing water hammer impact | Protect water pumps and pipes from high pressure shock damage |
| Corrosion resistance | Stainless steel or special coating valve body is suitable for fertilizer and pesticide environment | Extending the service life of irrigation systems in corrosive media |
